Literature

Features and Benefits:

• Volumetric or mass flow monitoring of most liquids, gases, and steam
• Multivariable meter delivers mass flow, temperature, pressure, and density readings from a single installed device and reduces initial cost, installation cost and cost of ownership over the lifetime of the instrument
• Compensated mass flow reading of liquids, gases, and steam
• Energy monitoring ability to compute and output energy use
• Easy to install and commission – Hot tappable, process shut down not required for installation
• Highly reliable - no moving parts, no fluid to sensor contact
• High accuracy with wide rangeability up to 100:1
• Handles temperatures up to 750 deg F
• Handles pressures up to 1500 psig
• Insertion style mounting permits installation in any pipe 2 inches and greater
• Field configurable ranges, outputs and displays
• Remote electronics option available for use in harsh environments or locations with limited access
• 4-20mZ loop-powered design saves on energy costs
• HART protocol communications (standard)
• Modbus communications available
• FM, FMC, ATEX, and IECEx Approved
