** V120-22-UN2 ** - 12/24VDC, 12 pnp/npn digital inputs, 2 universal inputs, 2 high-speed counter/shaft encoder inputs, 12 transistor outputs, 2 high-speed outputs, I/O Expansion port and 2 RS232/RS485 Ports.
Price:
$624.00
SKU:
V120-22-UN2
Brand:
Weight:
5.00 LBS
Shipping:
Calculated at checkout
Product Description
| Literature |
 |
- 10 Digital Inputs including 2 Inputs which can function as either high-speed counters, shaft encoders, frequency measurers or as normal digital inputs
- 2 Thermocouple / PT100 /Analog / Digital Inputs (can be used as inputs)
- 12 Transistor Outputs First 2 outputs can function as PWM
- Graphic Display
- 2 RS232/RS485 Communication Ports (selectable)
- MODbus
- GSM support - enables SMS messages
- 12/24 VDC power supply
